产品信息
| 产品型号 | 额定功率 | 额定力矩 | 额定转速 | 额定电流 | 峰值扭矩 | 峰值电流 |
| (Kw) | (Nm) | (rpm) | (Arms) | (Nm) | (Arms) | |
| 220VAC电压 | ||||||
| HYA65-5030A | 0.5 | 1.6 | 3000 | 4.3 | 4.53 | 14.7 |
| HYA10-1030A | 1 | 3.2 | 3000 | 5.6 | 9.6 | 20 |
| HYA10-1730A | 1.7 | 5.3 | 3000 | 9.1 | 16.5 | 36.2 |
| 380VAC电压 | ||||||
| HYA13-1620B | 1.6 | 7.5 | 2000 | 7 | 22.5 | 27.8 |
| HYA13-2820B | 2.8 | 13.4 | 2000 | 10.8 | 45 | 42.4 |
| HYA18-5020B | 5 | 24 | 2000 | 15.3 | 75 | 48.8 |
| HYA18-6520B | 6.5 | 31 | 2000 | 20.2 | 105 | 68.5 |
| HYA18-8020B | 8 | 38.5 | 2000 | 3 | 135 | 95 |
